MT-5110-C

Global
Taiwan
China

3 1/2 Capacitance Meter

Capacitance Measurement 0.1pF~20,000μF.

Please contact sales team for more information. Tel. +886-2-2218-3233

I would like to make a query

Features
Dealer
Support

Complies with the newest CE safety standard
3 1/2 digits 1999 counts.
High measuring accuracy: ±0.5%.
Measurements are possible even under a strong magnetic field.
LCD display for low power consumption and clear readout even in bright ambient light conditions.
Zero knob: Knob to zero when testing low capacitance.
Extra function: LCD backlight, low battery indication

Capacitance	200pF ±(0.5%+7d), 2n/20n/200n/2μ/20μ/200μF ±(0.5%+5d), 2,000μF ±(2.0%+5d), 20,000μF ±(3.0%+10d)
Zero adjustment	Manual (range:±20pF)
Over-input	Display shows “1”
Input overload protections	Y
Sampling time	0~5 second
EN61010-1	CE
Power source	NEDA1604/6F22 (9V) x 1pcs (Not included)
Size	182x90x46mm
Test Lead model no.	MT-9906

Shipping Instructions

PACKING	Color Box
QTY'/CTN	30
N.W.	17 Kg
G.W.	18 Kg
CUFT	2.79
M3 (CBM)	0.08
MOQ	0
